- Light, powerful ebikemotion rear-hub drive system / Range: up to 100km/62mi
- Lightweight low-drag BallisTec carbon frameset / Shimano Dura Ace Di2 electronic group
- HollowGram 45 SL KNØT carbon wheels / SAVE SystemBar
Where it thrives
The open road, up and down hills
What it's built for
Speed, efficiency, handling
The frame features highly truncated airfoil tube shapes that offer the same weight, and equal or better stiffness, than round tubes, but reduce drag by up to 30%.
The Mahle ebikemotion drive system uses a lightweight 250W rear hub motor and hidden 250Wh battery to provide three levels of "just-right" support. It's there when you need it, nearly imperceptible when you don't.
The integrated top tube controller lets you turn the system on, select your assist level and see your battery charge, all at the touch of a button, keeping your bars clean and uncluttered.
The Range Extender plugged into the charge port add 208W to the main battery for a total capacity of 450w, it works as a power bank and it charges the main battery while you're riding.
Hidden Cable Routing
Unique design routes brake lines through an opening in the front of the headtube for minimal drag and headache-free serviceability.
HollowGram SAVE SystemBar
This sleek, integrated handlebar system reduces drag and absorbs shock for more speed and better comfort. The two-piece design offers interchangeability and pitch adjust to fine tune your position.
HollowGram 45 KNØT Wheels
Our ultra-fast, low-drag, wide rim profile with a light, versatile 45mm depth. Maintains high aerodynamic efficiency even with big tires.
SAVE micro-suspension delivers an elegantly smooth ride. The low seat stays, integrated seat binder and KNØT 27 seatpost work in unison to absorb bumps, improve comfort and enhance control.
An integrated wheel sensor delivers hyper accurate speed, route and distance info, registers your bike, reminds you of needed service and more, all through the free Cannondale App.
Wheel SensorCannondale Wheel Sensor
Bottom BracketFSA T47 MegaEvo, threaded
ChainShimano HG701, 11-speed
CrankHollowGram, T47 w/ OPI SpideRing, 50/34
Front DerailleurShimano Dura-Ace Di2, braze-on
Rear CogsShimano Ultegra, 11-30, 11-speed
Rear DerailleurShimano Dura-Ace Di2
ShiftersShimano Dura-Ace Di2 hydro disc, 2x11
ForkAll-New, BallisTec Carbon, SAVE, 1-1/8" to 1-1/4" steerer, integrated crown race, 12x100mm Speed Release thru-axle, flat mount disc, internal routing, 55mm offset (S-M) 45mm offset (L)
FrameAll-New, BallisTec Carbon, internal downtube battery, integrated cable routing w/ Switchplate, dropout/axle spacing 135mm, SAVE, T47, flat mount disc, integrated seat binder
- Internal downtube battery
- Integrated cable routing w/ Switchplate
- Dropout/axle spacing 135mm
- Flat mount disc
- Integrated seat binder
HeadsetIntegrated Sealed Bearing, Tapered
Front HubVision Alloy, 12x100
Hubs(F) HollowGram KNØT, sealed bearing 12x100 centerlock / (R) ebikemotion X35 250W
Rear HubMAHLE ebikemotion X35 250W
RimsHollowGram 45 KNØT, Carbon, 20h front, 32h rear, 45mm deep, 21mm ID, tubeless ready
SpokesDT Swiss Aerolite
TiresVittoria Rubino Pro Bright Black, 700 x 25c
Brake LeversShimano Dura-Ace Di2 hydro disc
BrakesShimano Dura-Ace Di2 hydro disc, 160/160mm RT86 rotors
GripsPrologo One Touch
HandlebarHollowGram SystemBar SAVE, Carbon, 8 deg. pitch adjust
SaddlePrologo Dimension NDR, 143mm width, Tirox rails
SeatpostAll-New HollowGram 27 SL KNØT, carbon, 2 bolt clamp, 330mm
StemHollowGram KNØT, alloy w/ cable cover, -6°
E-System BatteryMAHLE ebikemotion X35 250Wh
E-System ChargerMAHLE ebikemotion X35
|A Seat Tube Length||47.7 121cm||51.5 130cm||53.6 136cm|
|B Top Tube Length||53.4 135cm||54.6 138cm||55.7 141cm|
|D Head Tube Angle||71.2° 71.2°||71.2° 71.2°||73.0° 73.0°|
|E1 Seat Tube Angle Effective||73.7° 73.7°||73.7° 73.7°||73.7° 73.7°|
|F Standover||75.8 192cm||78.8 200cm||80.8 205cm|
|H Wheelbase||100.6 255cm||101.8 258cm||100.2 254cm|
|I Front Center||59.8 151cm||61.1 155cm||59.4 150cm|
|J Chain Stay Length||41.8 106cm||41.8 106cm||41.8 106cm|
|K Bottom Bracket Drop||7.2 18cm||7.2 18cm||7.2 18cm|
|L Estimated BB Height||27.1 68cm||27.1 68cm||27.1 68cm|
|M Fork Rake||5.5 13cm||5.5 13cm||4.5 11cm|
|N Trail||5.8 14cm||5.8 14cm||5.8 14cm|
|O Stack||53.4 135cm||55.4 140cm||57.4 145cm|
|P Reach||37.8 96cm||38.4 97cm||38.9 98cm|
