          Level Up

          Fast, fun, and functional. A hardtail e-mountain bike built to tackle any challenge, on the trail or off.

          What it's for

          Conquering trails, chasing adventure, around-town errands and fun

          Highlights

          • The rugged aluminum frame features an integrated front running light, plus mounts for kickstand, rack and fenders.
          • Bosch’s sporty and versatile Performance Line drive unit delivers up to 65Nm of torque, and 300% support, in a quiet, natural feeling way.
          • A removable, 625Wh battery provides tons of range for exploration and adventure.
          • The durable, reliable, Shimano CUES U6000 10-speed group offers smooth shifting and a wide gear range.
          • The Suntour XCM 34 fork features 100mm of travel, and wide, 34mm stanchions for precise steering.

          Level Up

          This rugged, fun-loving, electric mountain bike is ready to take your trail-riding game to a whole new level. Sporting a powerful Bosch drive system, long-lasting battery and trail-ready components, it lives to conquer the hills and carve the canyons. Or equip it with racks, fenders and lights, and cruise your daily commute. Trail Neo is ready for anything.
          AT A GLANCE
          Bosch Battery – 625Wh PowerTube

          A large 625Wh battery means you have all the juice you need to get where you’re going and back.

          AT A GLANCE
          25 km/h Assist

          This e-bike drive system provides pedal assist up to a maximum speed of 25km/h. Above that, it’s all you.

          AT A GLANCE
          Range up to 140km / 87mi

          Plenty of power to go the distance. Ride longer. Have more fun.

          Features

          Powered Up

          Bosch’s Performance Line drive unit offers 65Nm of torque and can boost your pedaling power up to 300%. Paired with a 625Wh battery, it lets you conquer climbs, accelerate effortlessly, and go for hours.

          Confident Capability

          Trail Neo's battery and drive unit are positioned as low and centrally as possible in the frame. Combined with responsive rear-end geometry and a slack headtube angle, the result is a perfect blend of stability and agility on any trail.

          Ready for Anything

          Rugged trail components like powerful hydraulic brakes, a stout 100mm fork, and a wide handlebar put you in complete control off-road. But it’s versatile, too. An integrated running light in the headtube, wiring for a lighting system, plus clever mounts for racks, fenders, and a kickstand make it a fantastic do-it-all machine.

          Keep it Quick

          The proven quick-release rear axle standard means you don’t need additional tools for removing the rear wheel.

          Make More of Your Ride

          When fun and function are both important, you can use the headtube mounts for water bottles or gear, and the kickstand mount for around-town convenience.

          The Lighter Side

          The integrated front running light helps you stand out on the road.

          Specs

          Details

          • Platform
            Trail Neo
          • Model Name
            Trail Neo 3
          • Model Code
            C61353U

          Frameset

          • Frame
            SmartForm C2 Alloy, removable 625Wh downtube battery, integrated front running light, tapered headtube, internal cable routing, 135mm QR hub spacing, IS disc mount, motor protection, headtube rack mounts, 40mm Pletscher kickstand mount, rack & fender mounts
          • Fork
            SR Suntour XCM 34 Boost, 100mm, Coil, 46mm offset
          • Headset
            Integrated, 1-1/8 to 1.5", sealed bearings

          E-System

          • Drive Unit
            Bosch Performance Line
          • Battery
            Bosch PowerTube, 625Wh
          • Charger
            Bosch 4A
          • Display
            Bosch Intuvia w/LED remote

          Drivetrain

          • Rear Derailleur
            Shimano CUES U6000
          • Shifters
            Shimano CUES U6000, 10-speed
          • Chain
            KMC E500
          • Crank
            FSA Bosch Gen3, 170mm, 38T
          • Rear Cogs
            Shimano CUES LG400, 11-48, 10-speed

          Brakes

          • Brakes
            Shimano MT200 hydraulic disc, 180/180mm RT30/RT-EM300 rotors
          • Brake Levers
            Shimano MT200 hydraulic disc

          Wheels

          • Rims
            WTB STX i25 TCS, 32h, tubeless ready
          • Spokes
            DT Swiss Champion 2.0
          • Tire Size
            2.4
          • Wheel Size
            29
          • Hubs
            (F) Shimano MT400, 15x110mm thru-axle / (R) Shimano UR600, 9x135mm QR
          • Tires
            Maxxis Ardent, 29x2.4" (M, L, XL) 27.5x2.4" (S), EXO Protection

          Components

          • Handlebar
            Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm, 31.8mm
          • Stem
            Cannondale 3, 3D Forged 6061 alloy, 1-1/8", 31.8, 0°
          • Grips
            Fabric Funguy
          • Saddle
            Cannondale Ergo XC
          • Seatpost
            Cannondale 3, 6061 Alloy, 31.6x350mm

          Extra

          • Extra 1
            Pre-installed light cables

          Please note that, based on component availability and other factors, specifications are subject to change without notice.
