Moterra Neo Carbon SE

+Compare

Moterra Neo Carbon SE

    Close

    Sizing

    Tell us how tall you are, we'll help you find the right size.

    Long arms? Short Legs? Just not sure? Call us!

    Close

    Retailers

      Platform: Moterra Neo

      Boundless

      An e-mountain bike with infinite capability. The shackles are off, go ride the unrideable. Again and again.

      Highlights

      • Proportional Response Tuned Carbon frame, 160mm / RockShox Boxxer Select Charger RC 180mm fork
      • New SRAM GX/NX 12-speed shifting / SRAM Code R 4-piston brakes
      • Bosch Performance Line CX drive unit / 625Wh battery / Range: up to 102km (63mi)

      Where it thrives

      Challenging trails, up and down hills, out in the elements

      What it's built for

      Traction, speed, handling

      Boundless.

      Impressively precise. Uncommonly agile. With its low center of gravity, modern geometry and short chainstays, Moterra's handling is in a class of its own.

      Power & style

      More Info

      Bosch's powerful new Performance CX drive unit and a long-lasting PowerTube battery integrate cleanly into Moterra's burly carbon frame. The power and range to ride anything — in a beautiful package.

      Proportional Response

      More Info

      Riders come in all sizes. Proportional Response is the only design that addresses this fact, tailoring the suspension layout by size so that every rider gets optimal traction, suppleness and control.

      Technology

      Moterra Neo: Anything's Possible

      PLAY FILM

      Drivetrain

      • Chain
        SRAM NX Eagle, 12-speed
      • Crank
        FSA Bosch E-bike w/ custom Ai offset, 160mm, 34T
      • Rear Cogs
        SRAM XG-1275 Eagle, 10-52, 12-speed
      • Rear Derailleur
        SRAM GX Eagle
      • Shifters
        SRAM NX Eagle, single click, 12-speed

      Frameset

      • Fork
        RockShox Boxxer Select Charger RC, 180mm, DebonAir, 20x110, 56mm offset
      • Frame
        160mm travel, BallisTec Carbon Front Triangle, SmartForm C1 Alloy Swingarm, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, Ai offset drivetrain, internal cable routing, 148x12mm thru-axle, post mount brake, tapered headtube
      • Headset
        Integrated Sealed Bearing, Tapered
      • Rear Shock
        RockShox Super Deluxe Select

      Wheels

      • Front Hub
        Formula 20x110mm Boost
      • Front Tire
        Maxxis Assegai, 27.5/29 x 2.6", dual compount, EXO, tubeless ready
      • Rear Hub
        SRAM MTH 700, 12 x 148, XD Driver
      • Rear Tire
        Maxxis Assegai, 27.5/29 x 2.6", dual compount, EXO, tubeless ready
      • Rims
        WTB KOM Trail i30 TCS, 32h, tubeless ready
      • Spokes
        DT Swiss Champion
      • Tire Size
        2.5
      • Tires
        Maxxis Assegai, 27.5/29 x 2.5", Dual compound, EXO puncture protection, tubeless ready
      • Wheel Size
        29

      Brakes

      • Brake Levers
        SRAM Code R hydraulic disc
      • Brakes
        SRAM Code R hydraulic disc, 4-piston, CenterLine 200/200mm rotors

      Components

      • Grips
        Fabric FunGuy
      • Handlebar
        Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
      • Saddle
        Fabric Scoop Shallow Sport, steel rails
      • Seatpost
        Cannondale DownLow Dropper, internal routing, 31.6, 100mm (S), 125mm (M), 150mm (L/XL)
      • Stem
        Cannondale 1, 3D Forged 6061 Alloy, 1-1/8", 31.8, 7°

      E-System

      • E-System Battery
        Bosch PowerTube 625Wh
      • E-System Charger
        Bosch 4A
      • E-System Display
        Bosch Purion

      Extra

      • Extra 1
        Preinstalled light cables

      Measurements

      • Size: SM
        5'2" 157
        5'5" 165
      • Size: MD
        5'6" 167
        5'9" 175
      • Size: LG
        5'8" 172
        6'0" 182
      • Size: XL
        6'1" 185
        6'5" 195
