Trail Neo 1

Color:

We've got you covered.

Limited Lifetime Warranty

Every Cannondale bicycle comes with a limited lifetime warranty on the frame, and a one year warranty on all Cannondale components.

See complete warranty policy details. Some components have additional warranty coverage provided by the component manufacturer.

Bicycle warranty claims are handled through your Authorized Cannondale Retailer. To place a warranty claim on Cannondale gear or accessories, contact Cannondale Rider Services at 00800 32132123.

Worldwide Dealer Network

Looking to shop local? Try our Dealer Locator.

It's the easiest way to browse shops near you that carry Cannondale bikes. All the shops featured on our website are independent, authorized Cannondale retailers, so you can support local businesses while still finding the best bike—talk about a win-win.

sizing dialogue entered

Long arms? Short Legs? Just not sure? Call us!

Some models run larger than others. Customer Service can help you identify a size more specific to your body type. Call 1-800-245-3872.

Overview

Level Up

An e-mountain bike that will raise your game and ignite a passion for the trail.

Where it thrives

Low-impact trails, near and far

What it's built for

Speed, efficiency, handling

Highlights

Premium SmartForm C1 Alloy frame, removable 750Wh internal battery
Shimano Deore 12-speed drivetrain / MT420 hydraulic disc brakes
Bosch SmartSystem w/ Performance Line CX drive unit / 750Wh battery / Kiox display / Range: up to 175km

Level up

Smart power, big range

This e-bike is powered by Bosch’s new Smart System, featuring a huge 750Wh battery, Performance Line CX motor, LED remote and Kiox 300 display. Effortless acceleration, compelling versatility, and a range of up to 175km on a single charge.

Confident handling

Trail Neo's battery and drive unit are positioned as low and centrally as possible in the frame. Combined with responsive rear-end geometry and a slack headtube angle, the result is a perfect blend of stability and agility on any trail.

Ready for anything

Updated with the ability to explore further, faster, with more confidence than ever before. True mountain bike specs define Trail Neo: powerful hydraulic brakes, a wide handlebar, and a short stem. But it’s versatile, too, with pre-wiring for a lighting system, and clever mounts for racks, fenders and a kickstand.

The Performance Line CX drive unit and long-lasting 750Wh PowerTube battery make up Bosch's most powerful e-bike system. Increased torque of 85Nm and extended boost for effortless speed and endless fun.

Bosch Smart System

The fully networked Bosch drive system can be controlled and customized via their eBike Flow app, and is regularly updated 'over the air' for a totally connected and personalized ride experience.

Right Sized Wheels

The small size of the Trail Neo 1 rolls on 27.5" wheels, while the larger sizes come with 29" wheels to deliver the best blend of fit, fast and fun for every rider.

Be Visible

A running light integrated into the headtube to make you more visible, day or night. If you need more, there's also pre-wiring up front for more lighting that can run off of the bike's battery.

Specs

Details

Platform
Trail Neo
Model Name
Trail Neo 1
Model Code
C61171M

Frameset

Frame
SmartForm C1 Alloy, removable 750Wh downtube battery (dual battery ready), integrated front running light, tapered headtube, internal cable routing, 135mm QR hub spacing, IS disc mount, motor protection, headtube rack mounts, 40mm Pletscher kickstand mount, rack & fender mounts
Fork
RockShox 35 Silver, 100mm, Coil, 15x110mm thru-axle, tapered steerer, 44mm offset
Headset
Integrated, 1-1/8 to 1.8", sealed angular contact bearings

E-System

Drive Unit
Bosch Performance Line CX 250W
Battery
Bosch PowerTube, 750Wh
Charger
Bosch 4A
Display
Bosch Kiox 300 w/ LED remote

Drivetrain

Rear Derailleur
Shimano Deore M6100
Shifters
Shimano Deore M6100, 12-speed
Chain
Shimano Deore M6100, 12-speed
Crank
FSA for Bosch G4
Rear Cogs
Shimano Deore M6100, 10-51, 12-speed

Brakes

Brakes
Tektro M807 4-piston hydraulic disc brakes, 203/203 TRP Rotors
Brake Levers
Tektro M807 hydraulic disc

Wheels

Rims
WTB STX i30, 32h, tubeless ready
Spokes
DT Swiss Champion 2.0
Tire Size
2.6
Wheel Size
27.5/29
Hubs
(F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT510, 12x148mm thru-axle
Tires
Maxxis Rekon, 29x2.6" (M, L, XL) 27.5x2.6" (S), EXO Protection, tubeless ready

Components

Handlebar
Cannondale 2 Riser, 6061 Alloy, 35mm OD, 25mm rise, 8° sweep, 5° rise, 780mm
Stem
Cannondale 2, 3D Forged 6061 Alloy, 1-1/8", 35mm, 0°, internal cable guide
Grips
Fabric Funguy
Saddle
Selle Royal Vivo Active Ergo Reflective
Seatpost
Cannondale 4, 6061 Alloy, 31.6x350mm

Extra

Extra 1
Pre-installed light cable

Please note that, based on component availability and other factors, specifications are subject to change without notice.
