          The New Cutting Edge

          This is the ultimate XC race bike. Ground-breaking suspension, aggressive geometry and feathery weight let you go full gas from the gun.

          Where it thrives

          On the race course

          What it's built for

          Chasing podiums

          Highlights

          • Lightweight carbon FlexPivot frame / Fox Float Performance 32 SC fork - 100mm travel F/R
          • Shimano XT/Deore 12-speed shifting / Deore 6100 hydraulic disc brakes
          • WTB STX i23 tubeless-ready rims / Shimano MT400 hubs

          The New Cutting Edge

          Suspension for speed

          More Info

          The most advanced suspension ever made for XC. While others sacrifice performance to save weight, our patented FlexPivot suspension delivers both. Incredibly light, with unreal grip, acceleration and control, it lets you go flat-out everywhere. More speed. More fun.

          Degrees of difference

          More Info

          Scalpel’s progressive geometry has evolved even further – we have a full degree and a half slacker headtube angle, one-degree steeper seat tube angle – creating an XC bike that’s more aggressive, lightning-fast, fun and stable everywhere, from the World Cup to your local loop.

          Technology

          Stiff. Light. Fast.
          At just over 1900 grams, complete with shock, the new Scalpel frame is one of the lightest full suspension MTB frames on the market. Incredible suspension, impeccable handling and feathery weight – it’s a recipe for victory.

          The New Cutting Edge

          PLAY FILM

          Specs

          Details

          • Platform
          • Model Name
            Scalpel Carbon 4
          • Model Code
            C24402M

          Frameset

          • Frame
            Scalpel Carbon, 100mm travel, Proportional Response Tuned, FlexPivot Chainstay, PF30-83, Tapered Headtube, Speed Release 12mm thru axle, Ai Offset, Stash compatible
          • Fork
            Fox Float Performance 32 SC, 100mm, 15x110mm thru-axle, tapered steerer, 51mm offset, remote-actuated
          • Headset
            Integrated Sealed Bearing, Tapered
          • Rear Shock
            Fox Float DPS Performance Elite EVOL, remote lockout, adjustable rebound

          Drivetrain

          • Rear Derailleur
            Shimano XT
          • Shifters
            Shimano Deore M6100, 12-speed
          • Chain
            Shimano Deore 6100, 12-speed
          • Crank
            Cannondale 1, BB30a, OPI SpideRing, 32T, Ai Offset
          • Rear Cogs
            Shimano Deore M6100, 10-51, 12-speed
          • Bottom Bracket
            Cannondale Alloy PressFit30

          Brakes

          • Brakes
            Shimano Deore 6100 hydraulic disc, 160/160mm RT54 rotors
          • Brake Levers
            Shimano Deore hydraulic disc

          Wheels

          • Rims
            WTB STX i23 TCS, 32h, tubeless ready
          • Spokes
            DT Swiss Champion
          • Tire Size
            2.2
          • Wheel Size
            29
          • Hubs
            (F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
          • Tires
            (F) Maxxis Ardent Race, 29x2.2", EXO Protection, tubeless ready, (R) Maxxis Recon Race, 29x2.2", EXO Protection, tubeless ready
          • Front Tire
            Maxxis Ardent Race, 29x2.2", EXO Protection, tubeless ready
          • Rear Tire
            Maxxis Recon Race, 29x2.2", EXO Protection, tubeless ready

          Components

          • Handlebar
            Cannondale 2 Flat, butted 2014 Alloy, 31.8mm, 3° rise, 8° sweep, 760mm
          • Stem
            Cannondale 2, 6061 Alloy, 35mm, 0°
          • Grips
            Cannondale Locking Grips
          • Saddle
            Cannondale Scoop Shallow Sport, steel rails
          • Seatpost
            Cannondale 2, 7075 Alloy, 31.6x400mm

          Please note that, based on component availability and other factors, specifications are subject to change without notice.
