Quick Neo | E- Fitness | Electric

Quick Neo

+Compare
Quick Neo
Find other local bike shops to check for availability

Platform: Quick Neo

On the move.

A swift, powerful e-bike that’s perfect for speedy workouts, long distance cruising or sporty transportation.

Highlights

  • Premium SmartForm C1 Alloy frame and carbon fiber fork
  • Integrated connectivity with Cannondale App / Shimano 9-speed drivetrain
  • Bosch Active Line Plus 250W drive-unit / 400Wh battery / Range: up to 115km (72mi)

Where it thrives

In town, leisurely rides, on crowded streets

What it's built for

Efficiency, visibility, agility

International Connectivity

  • Wheel Sensor
    Cannondale Wheel Sensor

Drivetrain

  • Chain
    Shimano HG93, 9-speed
  • Crank
    Bosch Gen3 w/ custom Ai offset spider, 38T
  • Pedals
    Cannondale Urban Pedal
  • Rear Cogs
    Shimano HG200, 11-36, 9-speed
  • Rear Derailleur
    Shimano Altus
  • Shifters
    Shimano Altus, 9-speed

Frameset

  • Fork
    BallisTec Carbon, 1-1/8" to 1.5" tapered steerer, 55mm offset, flat mount, 12x100 thru axle
  • Frame
    SmartForm C1 Alloy, SAVE, Ai, flat mount brake, 142x12 thru-axle
    • SAVE
    • Ai
    • Flat mount brake
    • 142x12 thru-axle
  • Headset
    Integrated, 1-1/8 to 1.5", sealed angular contact bearings

Wheels

  • Front Hub
    Formula RX-512 12x100
  • Hubs
    (F) Formula RX-512 12x100 / (R) Formula DC-142 12x142
  • Rear Hub
    Formula DC-142 12x142
  • Rims
    Cannondale 2, 32h, Double wall
  • Spokes
    DT Swiss Champion
  • Tire Size
    35
  • Tires
    Schwalbe G-One Allround Performance, 700 x 35c, RaceGuard, tubeless ready
  • Wheel Size
    700c

Brakes

  • Brake Levers
    Shimano MT200 hydro disc
  • Brakes
    Shimano MT200 hydro disc, 160/160mm RT26 rotors

Components

  • Grips
    Cannondale Ergo Fitness Dual Density, Lock-on
  • Handlebar
    Cannondale 3 Flat, 6061 double-butted Alloy, 8° sweep, 720mm
  • Saddle
    Fabric Scoop Radius Sport, steel rails
  • Seatpost
    Cannondale 3, 6061 Alloy, 25.4X350MM S/M, 400MM LG/XL
  • Stem
    Cannondale 3, 6061 Alloy, 31.8, 7°

E-System

  • E-System Battery
    Bosch PowerTube 400Wh
  • E-System Charger
    Bosch 2a
  • E-System Display
    Bosch Purion
  • Drive Unit
    Bosch Active Line Plus 250W

Measurements

  SM MD LG XL
A Seat Tube Length 44.5cm 17 49cm 19 53.5cm 21 58cm 22
B Top Tube Length 53.5cm 21 55.2cm 21 57.6cm 22 59.7cm 23
C Top Tube Actual 0cm 0 0cm 0 0cm 0 0cm 0
D Head Tube Angle 71.0 71.0 71.0 71.0 71.0 71.0 71.0 71.0
E1 Seat Tube Angle Effective 74.0° 74.0° 74.0° 74.0° 73.5° 73.5° 73.0° 73.0°
F Standover 73cm 28 77cm 30 81cm 31 85cm 33
G Head Tube Length 12.6cm 4 15.7cm 6 19.1cm 7 22.2cm 8
H Wheelbase 103.4cm 40 105.3cm 41 107.3cm 42 103.4cm 40
I Front Center 0cm 0 0cm 0 0cm 0 0cm 0
J Chain Stay Length 43.8cm 17 43.8cm 17 43.8cm 17 43.8cm 17
K Bottom Bracket Drop 6.7cm 2 6.7cm 2 6.7cm 2 6.7cm 2
L Estimated BB Height 0cm 0 0cm 0 0cm 0 0cm 0
M Fork Rake 0cm 0 0cm 0 0cm 0 0cm 0
N Trail 0cm 0 0cm 0 0cm 0 0cm 0
O Stack 54.5cm 21 57.5cm 22 60.7cm 23 54.5cm 21
P Reach 37.9cm 14 38.7cm 15 39.6cm 15 37.9cm 14
