Cannondale: Quick Neo EQ | E- Fitness | Electric

Quick Neo EQ

+Compare
Quick Neo EQ
Find a bike shop
Find other local bike shops to check for availability

Platform: Quick Neo

Accelerate Your Life.

Life moves fast. Make the most of it on the Tesoro Neo. Power up your morning commute, beat traffic at its own game, or leave your worries behind on getaway adventures with this sportive, versatile machine.

Highlights

  • Bosch Active Line Plus 250W Drive / PowerTube 500Wh Battery
  • Shimano Deore Drivetrain, 10-speed / MT200 Hydro Disc Brakes
  • Supernova Mini 2 front / E3 Tail Light 2 rear, Tubus Wingee Fenders & Rear Rack

Drivetrain

  • Chain
    Shimano HG54, 10-speed
  • Crank
    FSA E-bike, 170mm, Gen3, 38t
  • Pedals
    Cannondale Urban Pedal
  • Rear Cogs
    Shimano HG500, 11-42, 10-speed
  • Rear Derailleur
    Shimano Deore GS
  • Shifters
    Shimano Deore, 10-speed

Frameset

  • Fork
    ALL-NEW Quick NEO Disc, BallisTec Carbon, 1-1/8" to 1.5" tapered steerer, 55mm offset, flat mount, 12x100 thru axle
  • Frame
    ALL-NEW Quick NEO, SmartForm C1 Alloy, SAVE, Ai, flat mount brake, 142x12 thru-axle
  • Headset
    Integrated, 1-1/8 to 1.5", sealed angular contact bearings

Wheels

  • Hubs
    Formula DC-512 front, DC-142 rear
  • Rims
    Cannondale C2, 32h, Double wall
  • Spokes
    DT Swiss Champion
  • Tire Size
    34c
  • Tires
    WTB Exposure TCS, 700 x 34c, Distance + compound, tubeless ready
  • Wheel Size
    700c

Brakes

  • Brake Levers
    Shimano MT200 hydro disc
  • Brakes
    Shimano MT200 hydro disc, 160/160mm RT26 rotors

Components

  • Grips
    Cannondale Ergo Fitness Dual Density, Lock-on
  • Handlebar
    Cannondale C3 Flat, 6061 double-butted Alloy, 8° sweep, 720mm
  • Saddle
    Fabric Scoop Radius Elite, cro-mo rails
  • Seatpost
    Cannondale C3, 6061 Alloy, 25.4X350mm
  • Stem
    Cannondale C3, 6061 Alloy, 31.8, 7°

E-System

  • E-System Battery
    Bosch PowerTube 500Wh
  • E-System Charger
    Bosch 4A
  • E-System Display
    Bosch Kiox

Measurements

  SM MD LG XL
A Seat Tube Length 44.5 113cm 49.0 124cm 53.5 135cm 58.0 147cm
B Top Tube Length 53.5 135cm 55.2 140cm 57.6 146cm 59.7 151cm
C Top Tube Actual N/A 0cm N/A 0cm N/A 0cm N/A 0cm
D Head Tube Angle 71.0 71.0 71.0 71.0 71.0 71.0 71.0 71.0
E1 Seat Tube Angle Effective 74.0° 74.0° 74.0° 74.0° 73.5° 73.5° 73.0° 73.0°
F Standover 73.0 185cm 77.0 195cm 81.0 205cm 85.0 215cm
G Head Tube Length 12.6 32cm 15.7 39cm 19.1 48cm 22.2 56cm
H Wheelbase 103.4 262cm 105.3 267cm 107.3 272cm 103.4 262cm
I Front Center N/A 0cm N/A 0cm N/A 0cm N/A 0cm
J Chain Stay Length 43.8 111cm 43.8 111cm 43.8 111cm 43.8 111cm
K Bottom Bracket Drop 6.7 17cm 6.7 17cm 6.7 17cm 6.7 17cm
L Estimated BB Height N/A 0cm N/A 0cm N/A 0cm N/A 0cm
M Fork Rake N/A 0cm N/A 0cm N/A 0cm N/A 0cm
N Trail N/A 0cm N/A 0cm N/A 0cm N/A 0cm
O Stack 54.5 138cm 57.5 146cm 60.7 154cm 54.5 138cm
P Reach 37.9 96cm 38.7 98cm 39.6 100cm 37.9 96cm
