Cannondale: Quick Neo | E- Fitness | Electric

Quick Neo

+Compare
Quick Neo
Find a bike shop
Find other local bike shops to check for availability

Platform: Quick Neo

On The Move.

A swift, powerful e-bike that’s perfect for speedy workouts, long distance cruising or sporty transportation.

Highlights

  • Bosch Active Line Plus 250W Drive / PowerTube 500Wh Battery
  • Shimano Alivio/Altus Drivetrain / Shimano MT200 Hydro Disc Brakes
  • Schwalbe G-One Performance Allround Tires

Drivetrain

  • Chain
    Shimano HG93A, 9-speed
  • Crank
    FSA E-bike, 170mm, Gen3, 38t
  • Pedals
    Cannondale Urban Pedal
  • Rear Cogs
    Shimano HG201, 11-36, 9-speed
  • Rear Derailleur
    Shimano Alivio
  • Shifters
    Shimano Altus, 9-speed

Frameset

  • Fork
    ALL-NEW Quick NEO Disc, BallisTec Carbon, 1-1/8" to 1.5" tapered steerer, 55mm offset, flat mount, 12x100 thru axle
  • Frame
    ALL-NEW Quick NEO, SmartForm C1 Alloy, SAVE, Ai, flat mount brake, 142x12 thru-axle
  • Headset
    Integrated, 1-1/8 to 1.5", sealed angular contact bearings

Wheels

  • Hubs
    Formula RX-512 12x100 front, DC-142 rear
  • Rims
    Cannondale C2, 32h, Double wall
  • Spokes
    DT Swiss Champion
  • Tire Size
    35c
  • Tires
    Schwalbe G-One Performance Allround, 700x35c
  • Wheel Size
    700c

Brakes

  • Brake Levers
    Shimano MT200 hydro disc
  • Brakes
    Shimano MT200 hydro disc, 160/160mm RT26 rotors

Components

  • Grips
    Cannondale Ergo Fitness Dual Density, Lock-on
  • Handlebar
    Cannondale C3 Flat, 6061 double-butted Alloy, 8° sweep, 720mm
  • Saddle
    Fabric Scoop Radius Sport, steel rails
  • Seatpost
    Cannondale C3, 6061 Alloy, 25.4X350mm
  • Stem
    Cannondale C3, 6061 Alloy, 31.8, 7°

E-System

  • E-System Battery
    Bosch PowerTube 500Wh
  • E-System Charger
    Bosch 2A
  • E-System Display
    Bosch Purion

Measurements

  SM MD LG XL
A Seat Tube Length 44.5 113cm 49.0 124cm 53.5 135cm 58.0 147cm
B Top Tube Length 53.5 135cm 55.2 140cm 57.6 146cm 59.7 151cm
C Top Tube Actual N/A 0cm N/A 0cm N/A 0cm N/A 0cm
D Head Tube Angle 71.0 71.0 71.0 71.0 71.0 71.0 71.0 71.0
E1 Seat Tube Angle Effective 74.0° 74.0° 74.0° 74.0° 73.5° 73.5° 73.0° 73.0°
F Standover 73.0 185cm 77.0 195cm 81.0 205cm 85.0 215cm
G Head Tube Length 12.6 32cm 15.7 39cm 19.1 48cm 22.2 56cm
H Wheelbase 103.4 262cm 105.3 267cm 107.3 272cm 103.4 262cm
I Front Center N/A 0cm N/A 0cm N/A 0cm N/A 0cm
J Chain Stay Length 43.8 111cm 43.8 111cm 43.8 111cm 43.8 111cm
K Bottom Bracket Drop 6.7 17cm 6.7 17cm 6.7 17cm 6.7 17cm
L Estimated BB Height N/A 0cm N/A 0cm N/A 0cm N/A 0cm
M Fork Rake N/A 0cm N/A 0cm N/A 0cm N/A 0cm
N Trail N/A 0cm N/A 0cm N/A 0cm N/A 0cm
O Stack 54.5 138cm 57.5 146cm 60.7 154cm 54.5 138cm
P Reach 37.9 96cm 38.7 98cm 39.6 100cm 37.9 96cm
