Better Bring Dave
Anywhere and everywhere – jump lines, street jibs, skatepark flow, pump-track laps, whatever. Dave’s into it.
Where it thrives
Jump lines, pump tracks, street flow
What it's built for
Flow, Flips, & Whips
Highlights
- Durable SmartForm C3 Alloy frame w/ Integrated Chain Tensioners
- Manitou Circus Expert 100mm air fork
- Maxxis DTH tires / Tektro cable actuated disc brake
Dave does this.
And this.
And this too.
Loves a bit of this.
Even does this.
This is Dave.
Specs
Details
-
Platform
-
Model NameDave Dirt Jump
-
Model CodeC29201U
Frameset
-
FrameC3 Alloy, Threaded BB, Disc Brake Mount, Integrated 1-1/8"-1.5" Tapered Headtube, 3/8" Dropout w/ Integrated Chain Tensioners
-
ForkManitou Circus Expert, Air w/ Rebound Adjust, 100mm, 20mm thru-axle, 1-1/8"-1-1/2" tapered steerer, preload adjuster, black stanchions
-
HeadsetIntegrated Sealed Bearing, Tapered
Drivetrain
-
Front DerailleurN/A
-
ChainKMC HL1 Wide
-
CrankTubular Cr-Mo 3pc., 170mm Arms, Cold Forged CR-MO 22mm x 8T Spline Spindle, 28T
-
Rear CogsSunrace 13T
-
Bottom BracketBMX Euro Type w/ Solid Spindle
Brakes
-
BrakesTektro mechanical disc, 160/160mm rotors
-
Brake LeversTektro 2 finger
Wheels
-
RimsAlloy, double wall, 32h
-
SpokesStainless steel, 14g
-
TiresMaxxis DTH 26 x 2.3"
-
Tire Size2.3
-
Wheel Size26
-
Hubs(F) Formula 20x110mm thru-axle / (R) Sealed bearing cassette, 3/8x17mm female bolt
-
Front TireMaxxis DTH 26 x 2.3"
-
Rear TireMaxxis DTH 26 x 2.3"
Components
-
HandlebarCannondale 3 Riser, 6061 Alloy, 30mm rise, 8° sweep, 6° rise, 780mm
-
StemCannondale 3, 6061 Alloy, 31.8, 0°
-
GripsCannondale TrailShroom
-
SaddleCannondale Magic Steel, steel rails
-
SeatpostCannondale 3, 6061 Alloy, 27.2 x 200mm
Please note that, based on component availability and other factors, specifications are subject to change without notice.
