Moterra Neo Carbon 2

Note: An additional $15 E-bike Battery Recycling fee will be added to each electric bike order. Learn more

Electric Bike Battery Recycling Program

Along with 20+ other leading bike companies, Cannondale is proud to be a part of the e-bike battery recycling program organized by PeopleForBikes and administrated by the not-for-profit Call2Recycle. Your payment of $15 goes to an industrywide fund that ensures batteries from Cannondale e-bikes are recycled at end of life and do not end up in landfills. Learn more at Call2Recycle.

      What's my size?

      Add To Cart
      Close

      Tell us how tall you are, we'll help you find the right size.

        Long arms? Short Legs? Just not sure? Call us!

        Some models run larger than others. Customer Service can help you identify a size more specific to your body type. Call 1-800-245-3872.
        Close

          Breaking Boundaries

          A dual-suspension e-mountain bike built to crush boundaries. With its intuitive handling & the power and range of the Bosch 750Wh system, nothing is out of reach.

          Where it thrives

          Challenging trails, Up and down hills, Out in the elements

          What it's built for

          Handling, Traction, Efficiency, Durability

          Highlights

          • Proportional Response Tuned carbon frame / RockShox Lyrik Select+ fork, 150mm travel
          • Bosch SmartSystem - 750wh battery & Performance CX motor
          • Shimano XT/SLX 12-speed drivetrain

          Breaking Boundaries

          From the high mountains to your local loops, this e-MTB will take you to a whole new level. Agile and quick on the climbs, stable and composed on even the nastiest descents, it makes the easy trails fun, and the hard trails electrifying. It’s the kind of machine that makes you lust for the next ride.

          Built for You
          Power and range are just the beginning. What makes the Moterra Neo really shine is how it handles. With our Proportional Response size-specific design, each frame size gets its own unique suspension layout, geometry, and frame construction, so it handles like it was built just for you. Because it was.

          Features

          Moterra Neo & Moterra Neo LT:
          Learn More

          PLAY FILM

          Specs

          Details

          • Platform
          • Model Name
            Moterra Neo Carbon 2
          • Model Code
            C25272U

          Frameset

          • Frame
            Moterra Neo Carbon Front Triangle, SmartForm C1 Alloy Swingarm, 150mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH hanger, post mount brake, 1.5” – 1.8” tapered headtube, 18mm two-bolt kickstand mount
          • Fork
            RockShox Lyrik Select, 150mm, DebonAir, 15x110mm thru-axle, tapered steered, 44mm offset
          • Headset
            Acros integrated sealed bearing, tapered
          • Rear Shock
            RockShox Deluxe Select+, DebonAir, 2-Pos mode adjust, adjustable rebound

          E-System

          • Drive Unit
            Bosch Performance Line CX 250W
          • Battery
            Bosch PowerTube, 750Wh
          • Charger
            Bosch 4A
          • Display
            Bosch Kiox 300 w/ LED remote

          Drivetrain

          • Rear Derailleur
            Shimano XT
          • Shifters
            Shimano SLX, 12-speed
          • Chain
            Shimano SLX, 12-speed
          • Crank
            FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
          • Rear Cogs
            Shimano SLX, 10-51, 12-speed

          Brakes

          • Brakes
            Shimano MT520 4-piston hydraulic disc, 203/203mm RT64 rotors
          • Brake Levers
            Shimano MT501 hydraulic disc

          Wheels

          • Rims
            WTB ST i30 TCS, 32h, tubeless ready
          • Spokes
            DT Swiss Champion
          • Tires
            (F) Maxxis Minion DHF, 29x2.6", EXO, tubeless ready / (R) Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready
          • Tire Size
            2.6
          • Wheel Size
            29
          • Hubs
            (F) Formula 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
          • Front Tire
            Maxxis Minion DHF, 29x2.6", EXO, tubeless ready
          • Rear Tire
            Maxxis Rekon, 29x2.6" (27.5x2.6" - size Small), EXO, tubeless ready

          Components

          • Handlebar
            Cannondale 3 Riser, 6061 Alloy, 25mm rise, 8° sweep, 5° rise, 800mm
          • Stem
            Cannondale 2, 6061 Alloy, 35mm, 0°
          • Grips
            Fabric FunGuy
          • Saddle
            Fabric Scoop Shallow Sport, steel rails
          • Seatpost
            Cannondale DownLow Dropper, internal routing, 31.6, 125mm (S), 150mm (M), 170mm (L-XL)

          Extra

          • Extra 1
            Pre-installed light cable

          Please note that, based on component availability and other factors, specifications are subject to change without notice.
