Cannondale: Fat CAAD | Trail Bikes | Mountain

Fat CAAD 1

+Compare
Fat CAAD 1
Find a bike shop
Find other local bike shops to check for availability

Platform: Fat CAAD

Fat and Fast.

A fat bike with the soul of a racer.

Highlights

  • Lefty Olaf Alloy, 2Spring, 100mm, PBR Isolated Damper with Fat tune
  • SRAM NX/GX Eagle Drivetrain, 12-speed / SRAM Guide T Hydro Disc Brakes
  • Sun Ringle Mulefü​​t 80 SL tubeless Rims / Maxxis Minion FBF front, Minion FBR rear tubeless ready Tires

Drivetrain

  • Bottom Bracket
    Cannondale BB30XL
  • Chain
    SRAM NX Eagle, 12-speed
  • Crank
    Cannondale Si, BB30, Ai Offset SpideRing, X-Sync®, 30T
  • Pedals
    Not Included
  • Rear Cogs
    SRAM PG-1230, NX Eagle, 11-50, 12-speed
  • Rear Derailleur
    SRAM GX Eagle
  • Shifters
    SRAM NX Eagle, 12-speed

Frameset

  • Fork
    Lefty Olaf Alloy, 2Spring, 100mm, PBR Isolated Damper with Fat tune, 60mm offset
  • Frame
    Fat CAAD, SmartForm C1 Alloy, BB30XL, SAVE, 1.5 Si head tube
  • Headset
    Cannondale HeadShok Si

Wheels

  • Hubs
    Lefty 73 front, Sun Ringle SRC 12x197 rear
  • Rims
    Sun Ringle Mulefüt 80 SL, tubeless ready
  • Spokes
    DT Swiss Competition
  • Tire Size
    4.0"
  • Tires
    Maxxis Minion FBF 26 x 4.0" front, FBR 4.0" rear, EXO, tubeless ready
  • Wheel Size
    26

Brakes

  • Brake Levers
    SRAM Guide T hydro disc
  • Brakes
    SRAM Guide T hydro disc, 180/160mm Centerline rotors

Components

  • Grips
    Cannondale Locking Grips
  • Handlebar
    Cannondale C3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 760mm
  • Saddle
    Fabric Scoop Shallow Elite, cro-mo rails
  • Seatpost
    TranzX Dropper Post, internal routing, 31.6, 120mm
  • Stem
    Cannondale C3, 3D Forged 6061 Alloy, 1.5", 31.8, 6°, 60mm

Measurements

  XS SM MD LG XL
A Seat Tube Length 37 93cm 39 99cm 44 111cm 49 124cm 54 137cm
B Top Tube Length 56.2 142cm 58.7 149cm 61 154cm 63.4 161cm 64.7 164cm
C Top Tube Actual 55.5 140cm 57.1 145cm 58.7 149cm 60.8 154cm 62.2 157cm
D Head Tube Angle 69.1° 69.1° 69.1° 69.1° 69.1° 69.1° 69.1° 69.1° 69.1° 69.1°
E1 Seat Tube Angle Effective 73.0° 73.0° 73.0° 73.0° 73.0° 73.0° 73.0° 73.0° 73.0° 73.0°
F Standover 76 193cm 76.4 194cm 80 203cm 83.8 212cm 87.4 221cm
G Head Tube Length 9.7 24cm 9.7 24cm 11 27cm 12.2 30cm 13.4 34cm
H Wheelbase 110.2 279cm 112.7 286cm 115.2 292cm 117.6 298cm 119 302cm
I Front Center 65.2 165cm 67.7 171cm 70.2 178cm 72.6 184cm 74 187cm
J Chain Stay Length 45.6 115cm 45.6 115cm 45.6 115cm 45.6 115cm 45.6 115cm
K Bottom Bracket Drop 5.8 14cm 5.8 14cm 5.8 14cm 5.8 14cm 5.8 14cm
L Estimated BB Height 32.4 82cm 32.4 82cm 32.4 82cm 32.4 82cm 32.4 82cm
M Fork Rake 6 15cm 6 15cm 6 15cm 6 15cm 6 15cm
N Trail 8.2 20cm 8.2 20cm 8.2 20cm 8.2 20cm 8.2 20cm
O Stack 60.7 154cm 60.7 154cm 61.9 157cm 63.1 160cm 64.2 163cm
P Reach 37.6 95cm 40.1 101cm 42.1 106cm 44.1 112cm 45.1 114cm
