Perfectly Framed
The SmartForm C2 Alloy frame perfectly balances toughness and refinement. The machined headtube, internally butted tubeset, and strengthening gussets are testaments to our decades of aluminum expertise.
sizing dialogue entered
Close
Tell us how tall you are, we'll help you find the right size.
Long arms? Short Legs? Just not sure? Call us!
Some models run larger than others. Customer Service can help you identify a size more specific to your body type. Call 1-800-245-3872.
What You Need
Full-tilt-boogie trail capability meets hardtail purity and simplicity. That's the beauty of Habit HT. Minimum fuss. Maximum fun.
Where it thrives
Trails of all kinds
What it's built for
Good times in the dirt
Highlights
- Light, durable SmartForm C2 Alloy frame / RockShox Judy TK airsprung fork
- SRAM Level hydraulic disc brakes / Wide range microSHIFT Advent X Pro 10-speed shifting
- Grippy 2.5" Maxxis Minion DHF & High Roller II tires / TranzX dropper post
What You Need
Rugged
When it's time to mess around, Habit HT doesn't mess around. The beautifully burly aluminum frame takes whatever the trail is dishing out and comes back for seconds.
Rowdy
Habit HT lives to let loose. Its dialed trail geometry can crush miles or session lines – or both on the same ride. Playful? Yup. Stable? Very. Fun? You have no idea.
Ready
Stout 130mm forks. Wide rims and big tires. Big-range 1x drivetrains, powerful brakes, and dropper posts. Ready-to-rock components mean Habit HT won't let you down when it's time to get sendy.
Features
Geometry Class
Incredible handling comes from incredible geometry. A slack 64° head angle and long front end bring full-throttle stability and confidence, while the tight rear end and appropriately steep 76° seat angle keep things nimble and help you put the power down on climbs.
Drop It
Dropper posts are standard equipment, as they should be. Less post = more fun!
Load It
Five threaded mounts in the main frame give you lots of options for bottles, pumps, or packs. Add our convenient StrapRack carrier for tools, tubes, or whatever else you feel like bringing along.
Universal Derailleur Hanger
The derailleur hanger is a quiet hero. It's designed to bend or break if your derailleur takes a hit. With the UDH, replacements are easy to find and easy to install. It also means the frame is compatible with SRAM T-Type Transmission drivetrains.
Specs
Details
-
Platform
-
Model NameHabit HT 2
-
Model CodeC26202U
Frameset
-
FrameHabit HT, SmartForm C2 Alloy, tapered headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA 73, 12mm thru axle, Boost 148, 55mm chainline, UDH hanger
-
ForkRockShox Judy TK, 130mm, Solo Air, 15x110mm thru-axle, tapered steerer, 42mm offset
-
HeadsetIntegrated Sealed Bearing, Tapered
Drivetrain
-
Rear DerailleurmicroSHIFT Advent X Pro
-
ShiftersmicroSHIFT Advent X Trail Pro, 10-speed
-
ChainKMC X10, 10-speed
-
CrankProwheel, 30T, 55mm chainline
-
Rear CogsmicroSHIFT Advent X Pro G-Series, 11-48, 10-speed
-
Bottom BracketProWheel BSA 73
Brakes
-
BrakesSRAM Level hydraulic disc 180/180mm CenterLine Rotors
-
Brake LeversSRAM Level hydraulic disc
Wheels
-
RimsWTB STX i30 TCS, 32h, tubeless ready
-
SpokesStainless Steel, 14g
-
Tire Size2.5
-
Wheel Size29
-
Hubs(F) Formula alloy, 15x110mm thru-axle / (R) Formula alloy 12x148mm thru-axle
-
Tires(F) Maxxis Minion DHF, 29x2.5", 3C, EXO, tubeless ready / (R) Maxxis High Roller II, 29x2.5", 3C, EXO+, tubeless ready
-
Front TireMaxxis Minion DHF, 29x2.5" , 3C, EXO, tubeless ready
-
Rear TireMaxxis High Roller II, 29x2.5" , 3C, EXO+, tubeless ready
Components
-
HandlebarCannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
-
StemCannondale 3, 6061 Alloy, 31.8, 0°
-
GripsCannondale TrailShroom
-
SaddleCannondale Ergo XC
-
SeatpostTranzX dropper, internal routing, 31.6, 100mm (S), 120mm (M), 130mm (L-XL)
Please note that, based on component availability and other factors, specifications are subject to change without notice.
