Go further.
A road bike that’s light, stiff, fast and surprisingly comfortable. Your rides will go longer. You'll barely notice.
Highlights
- Lightweight SmartForm C2 Alloy Frame w/ full carbon fork
- Shimano Tiagra 10-speed drivetrain w/ dual chainring FSA crank
- Promax Decoder R mechanical disc brakes
Feel the light
SmartForm C2 Alloy construction and full carbon forks deliver exceptionally light weight for this category for a high-performance feel.
Specs
Details
-
Platform
-
Model NameSynapse Tiagra
-
Model CodeC12601M
Frameset
-
FrameSmartForm C2 Alloy, SAVE, BB30, internal cable routing, flat mount, 130x9mm QR
-
ForkBallisTec Full Carbon, integrated crown race, SAVE, 12x100mm thru-axle, internal routing
-
HeadsetFSA Sealed Bearing, Integrated, 1-1/4"-1-1/8"
Drivetrain
-
Rear DerailleurShimano Tiagra GS
-
Front DerailleurShimano Tiagra, braze-on
-
ShiftersShimano Tiagra, 10-speed
-
ChainKMC X10EL, 10-speed
-
CrankFSA Omega ME Alloy, 50/34
-
Rear CogsShimano Tiagra, 11-34, 10-speed
-
Bottom BracketFSA Cartridge
Brakes
-
BrakesPromax Decoder R mechanical disc, 160/160mm rotors
-
Brake LeversShimano Tiagra
Wheels
-
Front HubFormula CRX-512, 12x100mm
-
Rear HubFormula DC-1422 QR
-
Brake TypeDisc
-
RimsRD 3.0, 28h
-
SpokesStainless Steel, 14g
-
Tire Size30
-
Wheel Size700c
-
TiresVittoria Zaffiro, 700x30c
Components
-
HandlebarCannondale 4, 6061 alloy, Compact
-
StemCannondale 4, 6061 Alloy, 31.8, 7°
-
GripsCannondale Bar Tape, 3.5mm
-
SaddleCannondale Stage Ergo
-
SeatpostCannondale 4, 6061 Alloy, 25.4x300mm (48-51), 350mm (54-56), 400mm (58-61)
Extra
-
Extra 1Removable fender bridge
Please note that, based on component availability and other factors, specifications are subject to change without notice.
