    Platform: Topstone

    Explore Further. Ride Freer.

    A capable, versatile gravel road bike. Built for chasing horizons, exploring routes less travelled or accelerating your commute.

    Highlights

    • Shimano 105 7000 Group, 11-speed
    • WTB ST i23 TCS tubeless Rims / WTB Nano TCS tubeless ready Tires
    • Cannondale Alloy Bar & Stem / Fabric Scoop Radius Sport Saddle

    Drivetrain

    • Bottom Bracket
      FSA MegaExo
    • Chain
      KMC X11EL, 11-speed
    • Crank
      FSA Omega ME Alloy, 46/30
    • Front Derailleur
      Shimano 105, 31.8 clamp
    • Rear Cogs
      Shimano 105, 11-34, 11-speed
    • Rear Derailleur
      Shimano 105 7000 GS
    • Shifters
      Shimano 105, 2x11

    Frameset

    • Fork
      Cannondale Topstone Disc, Full Carbon, 1-1/4" to 1-1/8" tapered steerer, 55mm offset, flat mount, 12x100 thru axle
    • Frame
      Topstone, SmartForm C2 Alloy, 142x12 thru-axle, tapered headtube, flat mount rear brake, internal cable routing
    • Headset
      Topstone Si, 25mm Alloy top cap

    Wheels

    • Front Tire
      WTB Nano TCS Light, 700 x 40c, tubeless ready
    • Hubs
      Formula RX-512 12x100 front, RX-142 12x142 rear
    • Rear Tire
      WTB Nano TCS Light, 700 x 40c, tubeless ready
    • Rims
      WTB ST i23 TCS, 28h, tubeless ready
    • Spokes
      Stainless Steel, 14g
    • Tire Size
      40c
    • Tires
      WTB Nano TCS, 700 x 40c, tubeless ready
    • Wheel Size
      700c

    Brakes

    • Brake Levers
      Shimano 105 7020 hydro disc
    • Brakes
      Shimano 105 7070 hydro disc, 160/160mm RT56 rotors

    Components

    • Grips
      Cannondale Grip Bar Tape w/Gel, 3.5mm
    • Handlebar
      Cannondale C3, butted 6061 Alloy, 16 deg flare drop
    • Saddle
      Fabric Scoop Radius Sport, steel rails
    • Seatpost
      Cannondale C3, 6061 Alloy, 27.2 x 350mm
    • Stem
      Cannondale C3, 6061 Alloy, 31.8, 7°

    Measurements

    • Size: XS
      5'0" 152
      5'5" 165
    • Size: SM
      5'4" 162
      5'9" 175
    • Size: MD
      5'7" 170
      6'1" 185
    • Size: LG
      5'11" 180
      6'4" 193
    • Size: XL
      6'3" 190
      6'8" 203
