SuperSix EVO Hi-MOD Disc Ultegra Di2
- Ultralight low-drag Hi-MOD BallisTec carbon frameset
- Integrated Cannondale App connectivity / HollowGram crank w/ power meter
- HollowGram 45 SL KNØT carbon wheels / SAVE SystemBar
Where it thrives
In competition, the open road, up and down hills
What it's built for
Speed, agility, handling
30 watts. That's how much power the drag-reducing tube shapes and integrated design of the new SuperSix EVO saves over the prior version at 30 mph (48.3 km/h).
Feel the light
The lightest disc brake road frameset we've ever made. The new SuperSix EVO is ready to throw down when the grade goes up.
Swift & sure
Racy geometry and stiffness for explosive speed. Better micro-suspension and big tire clearance for surprising smoothness. It all adds up to precise handling and a ride-feel that’s out of sight.
The frame features highly truncated airfoil tube shapes that offer the same weight, and equal or better stiffness than round tubes, but reduce drag by up to 30%.
Hidden Cable Routing
Unique design routes brake lines through an opening in the front of the headtube for minimal drag and headache-free serviceability.
SuperSix EVO has always been known for its elegantly smooth ride quality, and the new one is even smoother. The new SAVE rear stays, integrated binder and 27 SL KNØT seat post increase compliance by 18%.
The new frame design has clearance for some seriously big rubber. 30mm tires fit with ease, for new levels of comfort and capability on any kind of road.
HollowGram SAVE SystemBar
Thin bar profile absorbs shock and reduces drag for better comfort and speed. Two-piece design allows interchangeability and 8° of pitch adjustment to perfectly fine-tune rider position.
HollowGram 45 KNØT Wheels
An evolution of our wide, ultra-fast, low-drag rim profile with a light, versatile 45mm depth. Maintains high aerodynamic efficiency even with big tires.
An integrated wheel sensor delivers hyper accurate speed, route and distance info, registers your bike, reminds you of needed service and more, all through the free Cannondale App.
Power2Max Power Meter
Light, accurate and reliable Power2Max spider-based power meters are included on most models. Turn it on with a one-time activation fee and start getting faster. It's power made easy.
Speed Release Equipped
The Speed Release thru-axles allow faster, easier wheel changes and are compatible with most standard thru-axle wheelsets.
BallisTec Hi-MOD Carbon
Cannondale's premium high-strength, high-stiffness carbon construction. A sophisticated blend of high-strength and high-stiffness fibers yields a frame that’s extremely light, lively and durable.
Wheel SensorCannondale Wheel Sensor
Bottom BracketCannondale Alloy PressFit30
ChainShimano HG701, 11-speed
CrankHollowGram w/ pre-installed power2max NG Eco Power Meter (not activated), BB30a, FSA rings, 52/36
Front DerailleurShimano Ultegra Di2, braze-on
Rear CogsShimano 105, 11-30, 11-speed
Rear DerailleurShimano Ultegra Di2
ShiftersShimano Ultegra Di2 hydro disc, 2x11
ForkBallisTec Hi-MOD Carbon, SAVE, integrated crown race, 12x100mm Speed Release thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/4" steerer and 55mm offset (44-54cm), 1/8" to 1-3/8” steerer and 45mm offset (56-62cm)
FrameAll-New, BallisTec Hi-MOD Carbon, integrated cable routing w/ Switchplate, 142x12 Speed Release thru-axle, SAVE, PF30a, flat mount disc, integrated seat binder
- Integrated cable routing w/ Switchplate
- 142x12 Speed Release thru-axle
- Flat mount disc
- Integrated seat binder
HeadsetSuperSix, 1-1/4" lower bearing, 25mm top cap
Front HubHollowGram KNØT, sealed bearing 12x100 centerlock
Rear HubHollowGram KNØT, 12x142 centerlock w/ DT Swiss internals
RimsHollowGram 45 SL KNØT, Carbon, 20h front, 24h rear, 45mm deep, 21mm ID, tubeless ready
SpokesDT Swiss Aerolite
TiresVittoria Corsa, 700 x 25c
Brake LeversShimano Ultegra Di2 hydro disc
BrakesShimano Ultegra Di2 hydro disc, 160/140mm RT70 rotors
GripsCannondale Grip Bar Tape w/Gel, 3.5mm
HandlebarHollowGram SystemBar SAVE, Carbon, 8 deg. pitch adjust
SaddlePrologo Dimension NDR, 143mm width, Tirox rails
SeatpostAll-New HollowGram 27 SL KNØT, carbon, 2 bolt clamp, 330mm
StemAll-New HollowGram KNØT, alloy w/ cable cover, -6°
Weight: 7.6 kg / 16.8 lbs - Bike and frame weights may vary in final production.
5'3" 160 5'7" 170
5'5" 165 5'9" 175
5'7" 170 5'11" 180
5'10" 177 6'1" 185
6'0" 182 6'4" 193
6'2" 187 6'6" 198
6'5" 195 6'9" 205
