SystemSix Carbon Ultegra

+Compare

$4,750

Toggle Zoom

Color

Check Sizing Find a local retailer

SystemSix Carbon Ultegra

Color

Size

What's my size?

Check Retailers

Sizing

Tell us how tall you are, we'll help you find the right size.

Long arms? Short Legs? Just not sure? Call us!

Geometry

Choose a size or tell us how tall you are in the sizing section and we’ll give you all the measurements associated with your height here.

Retailers

Zip Code

Platform: SystemSix

Faster everywhere.

The fastest UCI-legal road bike in the world. More speed with less effort. Simple as that.

Highlights

Ultra low drag BallisTec carbon frameset
Shimano Ultegra hydro disc group / HollowGram crank
Vision SC55 Carbon wheelset

Where it thrives

In competition, the open road, up and down hills

What it's built for

Speed, efficiency, agility

SystemSix outstrips opponents, and not just where you’d expect. It sprints, descends and even climbs most hills faster, conserving watts off the front, in the draft, and in the laughing group.

SystemSix is a holistically designed, six-part system wholly dedicated to the pure pursuit of speed. It generates the least aerodynamic drag of any road bike on the market, which means more speed, in more situations, for more riders. It’s faster everywhere.

IT TAKES A SYSTEM TO WIN YOU SPEED

Learn more

Connectivity

Wheel Sensor
Cannondale Wheel Sensor

Drivetrain

Bottom Bracket
Cannondale Alloy PressFit30
Chain
Shimano HG601, 11-speed
Crank
HollowGram, BB30a w/ OPI SpideRing, 52/36
Front Derailleur
Shimano Ultegra, braze-on
Rear Cogs
Shimano 105, 11-30, 11-speed
Rear Derailleur
Shimano Ultegra GS
Shifters
Shimano Ultegra hydro disc, 2x11

Frameset

Fork
BallisTec Carbon, 1-1/8" - 1-1/4" steerer, 12x100mm Speed Release thru-axle, flat mount disc, 55mm offset (47-51cm) 45mm offset (54-62cm)
Frame
BallisTec Carbon, integrated cable routing w/ Switchplate, SAVE, PF30a, flat mount disc, 142x12 Speed Release thru-axle
- Integrated cable routing w/ Switchplate
- SAVE
- PF30a
- Flat mount disc
- 142x12 Speed Release thru-axle
Headset
Tapered, 1-1/8” upper, 1-1/4” lower bearing

Wheels

Front Hub
Vision Sealed Cartridge hub 12x100
Rear Hub
Vision Sealed Cartridge hub, 12x148
Rims
Vision SC55 Carbon Clincher 12x100 front, SC55 Carbon Clincher 12x142 rear
Spokes
Vision, Aero bladed
Tire Size
23 (26mm)
Tires
Vittoria Rubino Pro Speed, 700 x 26mm (23c)
Wheel Size
700c

Brakes

Brake Levers
Shimano Ultegra hydro disc
Brakes
Shimano Ultegra hydro disc, 160/140mm RT81 rotors

Components

Grips
Cannondale Grip Bar Tape w/Gel, 3.5mm
Handlebar
Vision Metron 4D Flat, UD Carbon
Saddle
Prologo Dimension STN NDR, steel rails
Seatpost
HollowGram 60 KNØT Carbon, 330mm
Stem
Vision Trimax OS, 2014 alloy, 3D Forged

Weight: 8.0 kg / 17.7 lbs - Bike and frame weights may vary in final production.

Measurements

Size: 47

5'3" 160
5'7" 170
Size: 51

5'5" 165
5'9" 175
Size: 54

5'7" 170
5'11" 180
Size: 56

5'10" 177
6'2" 187
Size: 58

6'0" 182
6'4" 193
Size: 60

6'2" 187
6'6" 198
Size: 62

6'5" 195
6'9" 205

Technology

System Integrated Design

The frame, fork and seatpost of the SystemSix were designed together holistically to minimize drag and optimize stiffness for maximum speed.

Customized Airfoils

Every section of the frame, fork and seatpost features it own customized truncated airfoil shape, designed to reduce drag across the effective yaw range.

HollowGram 60 KNØT Seatpost

An vital part of the system, the KNØT seatpost is designed specifically to reduce drag in the high speed airflow that is accelerated between the rider’s legs.

Hidden Cable Routing

Unique design routes brake lines and cables through an opening in the front of the headtube for minimal drag and headache-free serviceability.

Connected

An integrated wheel sensor delivers hyper accurate speed, route and distance info, registers your bike, reminds you of needed service and more, all through the free Cannondale App.

Speed Release Equipped

The Speed Release thru-axles allow faster, easier wheel changes and are compatible with most standard thru-axle wheelsets.

BallisTec Carbon

Cannondale's proprietary high-strength, high-stiffness carbon construction. An advanced matrix of intermediate modulus fibers creates a frame that's light, durable and lively.
