SystemSix Hi-MOD Red eTap AXS

+Compare

$11,000

Toggle Zoom

Color

Check Sizing Find a local retailer

SystemSix Hi-MOD Red eTap AXS Detail Image

SystemSix Hi-MOD Red eTap AXS

Color

Size

What's my size?

Check Retailers

Sizing

Tell us how tall you are, we'll help you find the right size.

Long arms? Short Legs? Just not sure? Call us!

Geometry

Choose a size or tell us how tall you are in the sizing section and we’ll give you all the measurements associated with your height here.

Retailers

Zip Code

Platform: SystemSix

Faster everywhere.

The fastest UCI-legal road bike in the world. More speed with less effort. Simple as that.

Highlights

Ultra low drag Hi-MOD BallisTec carbon frameset
SRAM RED eTap AXS hydro disc group
HollowGram 64 SL KNØT carbon wheelset / KNØT SystemBar

Where it thrives

In competition, the open road, up and down hills

What it's built for

Speed, efficiency, agility

SystemSix outstrips opponents, and not just where you’d expect. It sprints, descends and even climbs most hills faster, conserving watts off the front, in the draft, and in the laughing group.

SystemSix is a holistically designed, six-part system wholly dedicated to the pure pursuit of speed. It generates the least aerodynamic drag of any road bike on the market, which means more speed, in more situations, for more riders. It’s faster everywhere.

IT TAKES A SYSTEM TO WIN YOU SPEED

Learn more

Connectivity

Wheel Sensor
Cannondale Wheel Sensor

Drivetrain

Bottom Bracket
SRAM RED DUB PF30
Chain
SRAM RED, 12-speed
Crank
SRAM RED Carbon, 48/35
Front Derailleur
SRAM RED eTap AXS, braze-on
Rear Cogs
SRAM XG-1290, 10-28, 12-speed
Rear Derailleur
SRAM RED eTap AXS
Shifters
SRAM RED eTap AXS HRD, 2x12

Frameset

Fork
BallisTec Hi-MOD Carbon, 1-1/8" - 1-1/4" steerer, 12x100mm Speed Release thru-axle, flat mount disc, 55mm offset (47-51cm) 45mm offset (54-62cm)
Frame
BallisTec Hi-MOD Carbon, integrated cable routing w/ Switchplate, SAVE, PF30a, flat mount disc, 142x12 Speed Release thru-axle
- Integrated cable routing w/ Switchplate
- SAVE
- PF30a
- Flat mount disc
- 142x12 Speed Release thru-axle
Headset
Tapered, 1-1/8” upper, 1-1/4” lower bearing

Wheels

Front Hub
HollowGram KNØT, sealed bearing 12x100 centerlock
Rear Hub
HollowGram KNØT, 12x142 centerlock w/ DT Swiss internals, SRAM XDR driver
Rims
HollowGram 64 SL KNØT, Carbon, 20h front, 24h rear, 64mm deep, 21mm ID, tubeless ready
Spokes
DT Swiss Aerolite, straight pull
Tire Size
23 (26mm)
Tires
Vittoria Rubino Pro Speed, 700 x 26mm (23c)
Wheel Size
700c

Brakes

Brake Levers
SRAM RED eTap AXS HRD
Brakes
SRAM RED eTap AXS HRD, 160/160mm Centerlock rotors

Components

Grips
Cannondale Grip Bar Tape w/Gel, 3.5mm
Handlebar
HollowGram SystemBar KNØT, alloy w/ cable cover
Saddle
Prologo Dimension NDR, 143mm width, Tirox rails
Seatpost
HollowGram 60 KNØT Carbon, 330mm
Stem
HollowGram Stem KNØT, alloy w/ cable cover, -17°

Weight: 7.9 kg / 17.4 lbs - Bike and frame weights may vary in final production.

Measurements

Size: 47

5'3" 160
5'7" 170
Size: 51

5'5" 165
5'9" 175
Size: 54

5'7" 170
5'11" 180
Size: 56

5'10" 177
6'2" 187
Size: 58

6'0" 182
6'4" 193
Size: 60

6'2" 187
6'6" 198
Size: 62

6'5" 195
6'9" 205

Technology

Speed of Six

SystemSix is based on a six-part system - frame, fork, seatpost, bar, stem and wheels - designed together holistically to minimize drag, enhance comfort and optimize stiffness for maximum speed.

Cannondale KNØT SystemBar

Provides the low drag and sleek look of a one-piece system, with the fit and Interchangeability benefits of a two-piece bar and stem.

HollowGram 64 KNØT Wheels

One of the fastest wheelsets ever created. Ultra-wide, disc-only design offers incredibly low drag at a wide range of yaw angles, even with larger volume tires.

HollowGram 60 KNØT Seatpost

An vital part of the system, the KNØT seatpost is designed specifically to reduce drag in the high speed airflow that is accelerated between the rider’s legs.

Customized Airfoils

Every section of the frame, fork and seatpost features it own customized truncated airfoil shape, designed to reduce drag across the effective yaw range.

Hidden Cable Routing

Unique design routes brake lines and cables through an opening in the front of the headtube for minimal drag and headache-free serviceability.

Connected

An integrated wheel sensor delivers hyper accurate speed, route and distance info, registers your bike, reminds you of needed service and more, all through the free Cannondale App.

Speed Release Equipped

The Speed Release thru-axles allow faster, easier wheel changes and are compatible with most standard thru-axle wheelsets.

BallisTec Hi-MOD Carbon

Cannondale's premium high-strength, high-stiffness carbon construction. A sophisticated blend of high-strength and high-stiffness fibers yields a frame that’s extremely light, lively and durable.
